V-MINI-PRO Rear Hub Motor 1-9SP235RPM
Safe & Secure
Description
A strong motor but small motor for a small wheel
The V-MINI PRO is a ideal motor, the motor delivers more torque than a normal MINI motor. Due to its lightweight design and lightweight freewheel mechanism it feels nimble, and thus achieves a higher range on one battery charge.
The V-MINI PRO is suitable for mounting the standard Shimano disc. Especially suitable for light and heavier bikes.
This is delivered without rim and spokes, and is suited for a bike with rim brakes or disc brakes
Write Your Own Review
Specifications
Product Details
- Additional weight on bike
- 2,4 kg
- Width
- 80 mm
- Diameter
- 180mm
Technische eigenschappen
- Torque range
- 30 - 50Nm
- Maximum current
- 20A
- Suitable for more than one person bicycle
- Yes, but not optimal
- Material
- Alu
- Directional rotation
- Yes
- Maximum load
- High
- Motor Torque
- 25Nm
- Suitable for torque at low speeds
- Yes
- Replaceable
- Yes
- Voltage range
- 24 - 36V
- Efficiency
- 81%
- Motor type
- Indirect Drive, Outrunner
- Type controller
- Block and sinus wave
- Hall sensor
- No
- Rated motor RPM
- 235rpm
- Rated power
- 250Watt
Fysieke eigenschappen
- Possible number of gears
- 9
- Type of assembly
- Pinion
- Axle length
- 160mm
- Type of cable (wires)
- 3
- Axle diameter
- 12,5mm / 10mm
- Mounting width motor
- 135mm / 140mm
- Suitable for brake type
- Cantilever brake, Disc brake (Shimano)
- Number of spoke holes
- 36
- Suitable for wheel sizes
- 12", 14", 16", 18", 20"
- Suitable for Rollerbrake
- No
Geschikt voor
- Motor configured for
- (Sub) frame, Rear wheel
Gebruik
- Configuration for
- Bicycle, Hand bike, Hybrid bike, Mountain bike, Race bike, Recumbent bike, Special Aid bike, Sports bike
