DP (UK)
SKU
VFDP-GAS-6st
From €8.64
To €1,798.63 Regular Price €2,251.63
Safe & Secure
Description
DP normal setup for handbike.
Write Your Own Review
Specifications
Product Details
- Warranty
- 2 years, carry- in warranty
Technische eigenschappen
- Torque range
- 25 - 40Nm
- Estimated range
- 60 km ( combined consumption)
- Maximum current
- 20A
- Suitable for more than one person bicycle
- No
- Maximum supported speed
- 25 km/hr
- Motor Torque
- 30Nm
- Battery capacity
- 468Wh
- Maximum load
- High
- Levels of assistance
- 6 + 1 levels
- Suitable for torque at low speeds
- Yes
- Motor type
- Brushless, Indirect Drive, Outrunner
- Type controller
- Sinus wave
- Hall sensor
- No
- Rated motor RPM
- 235rpm
- Rated power
- 250Watt
- Free wheel function
- Yes
- Voltage
- 36V
- Additional LED indicator on battery
- Yes
Fysieke eigenschappen
- Additional weight on bike
- 4,8kg
- Possible number of gears
- na
- Type spaken
- Sapim G13, RVS (blank)
- Type of assembly
- Pinion
- Axle diameter
- 12,5mm / 10mm
- Mounting width motor
- 135mm / 140mm
- Removable battery
- Yes, with key lock
- Battery Mounting
- Bottle
- Suitable for brake type
- Roller brake (Shimano)
- Number of spoke holes
- 36
- Suitable for wheel sizes
- 20"
Montagelocatie
- Mounting location
- Front fork
Gebruiks eigenschappen
- Configuration for
- Hand bike
- Motor configured for
- Front wheel, Rear wheel
