Crystalyte Motor (FG2230-Brompton)
Safe & Secure
Description
The Crystalyte V-G motor is the hub motor with an eccentric appearance.
Suitable for the Brompton folding bike.
This motor is delivered without rim and spokes, and is suited for a bike with rim brakes.
Write Your Own Review
Specifications
Product Details
- Additional weight on bike
- 4,5 kg
- Width
- 60 mm
- Diameter
- 185 mm
- Brand
- Crystalyte
- warranty extensible
- Yes
- Warranty
- 2 years, carry- in warranty
Technische eigenschappen
- Voltage
- 36V
- Torque range
- 30 - 50Nm
- Suitable for more than one person bicycle
- Yes
- Material
- Metal
- Directional rotation
- No
- Maximum load
- Extra high
- Suitable for torque at low speeds
- Yes, but not optimal
- Replaceable
- Yes
- Voltage range
- 24 - 72V
- Efficiency
- 79%
- Motor type
- Brushless, Direct Drive, Outrunner, Sensor less
- Type controller
- Block and sinus wave
- Hall sensor
- Yes
- Rated motor RPM
- 260rpm
- Rated power
- 250Watt
- Number of magnets
- 40
Fysieke eigenschappen
- Cable length
- 40cm
- Axle length
- 190mm
- Type of cable (wires)
- 8
- Axle diameter
- 12,5mm / 7mm
- Mounting width motor
- 72mm
- Color
- Grey
- Suitable for brake type
- Cantilever brake
- Number of spoke holes
- 36
- Suitable for wheel sizes
- 14", 16", 18"
Geschikt voor
- Motor configured for
- Front wheel
Gebruik
- Configuration for
- Folding bike
