Middle Motor Conversion Set for Bicycle



Price as configured: €0.00

  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •

* Required Fields

Price as configured: €0.00

V-fiets-Middle Motor Conversion Set for Bicycle-31

Middle Motor Conversion Set for Bicycle

This middle motor conversion kit turns your bike into a Electrical bicycle with a higher range. This set has several bag and bottle battery options for different ranges. By placing the middle motor in your frame it will change your bicycle into an electric Bicycle. The battery can be mounted at the place of the water bottle on your frame. The optional battery in bag can be placed on a rear carrier.

This motor has a torque sensor for the pedalling power assist and this motor is suitable for different wheel sizes.

A round chain protector is included in the set for mounting the motor on bikes without chain protectors. Also the optional chain glider protector can be ordered for a complete cover of the chain front to rear.

 Tested by Bright TV (please see video below)

Please contact us first before you oder to make sure if this motor will fit your specific bike frame.

Additional Information

General

Warranty 2 years, carry- in warranty

Technical features

Torque range 50 - 70Nm
Suitable for more than one person bicycle No
Material Alu
Directional rotation Yes
Maximum supported speed 25 km/hr
Replaceable Yes
Motor Torque 70Nm
Battery technology Li-ION
Maximum load Normal
Suitable for torque at low speeds Yes
Efficiency 81%
Motor type Brushless, Indirect Drive, Inrunner
Type controller Sinus wave
Hall sensor Yes
Rated motor RPM +300rpm
Rated power 250Watt
Free wheel function Yes
Voltage 36V

Physical properties

Additional weight on bike 5,5 kg
Possible number of gears na
Color Black
Suitable for brake type Cantilever brake, Coaster brake, Disc brake (Shimano), Drum brake, Roller brake (Shimano)
Suitable for wheel sizes 16", 18", 20", 22", 24", 26", +28", 28"

Mounting location

Mounting location Crank

Usability

Configuration for 2-wheeled cargo bike, Bicycle, Hybrid bike, Mommy bike, Mountain bike, Race bike, Sports bike
Motor configured for (Sub) frame
